Model #:
SGV43C53UC
Color:
Custom Panel
300 Series, Dishwasher, 24''
300 Series, Dishwasher, 24''
Dimensions
Width: 23 9/16
Height: 32 1/16
Depth: 21 10/16
Color
Custom Panel
Features
- The Bosch 24” width ADA-compliant dishwasher is shorter than standard dishwashers and features sophisticated technologies for outstanding performance, quiet operation, remarkable flexibility and now with connected technology through Home Connect™.
- access additional wash cycles to choose the right one for your needs with Smart Cycle.
- 24h Delay Start Timer lets you run your dishwasher at off-peak times.
- uses Intelligent sensors to monitor the wash water and automatically adjust the cycle for a smarter clean.
- provide a smooth glide on all three racks.
- ensures optimally spot-free and shiny dishes.
Rebates
Specification
| General | |
| Third Rack | None |
| Product group | Dishwasher |
| Brand | Bosch |
| Accessories Parts | no |
| SKU | SGV43C53UC |
| Internal article number | SGV43C53UC |
| EAN code | 4242005415304 |
| Construction type | Built-in |
| Installation type | Full-integrated |
| Column installation | Yes |
| Type of control | Electronic |
| Type of control | push-button |
| Removable work top | No |
| Door decor panel | Possible but accessory |
| Tub material | Stainless steel |
| Hidden heating element | Yes |
| Watts (W) | 1440 |
| Current (A) | 12 |
| ChildLock | No |
| Volts (V) | 120 |
| Frequency (Hz) | 60 |
| Power cord length (cm) | 170.0 |
| Plug type | Nema5-15P |
| Length inlet hose (cm) | 165 |
| Length outlet hose (cm) | 190 |
| Adjustable plinth | No |
| Height of removable worktop (mm) | 0 |
| Power Cord Length | 67'' |
| Maximum adjustability feet (mm) | 60 |
| Depth with open door 90 degree (mm) | 1155 |
| Height of the packed product (mm) | 880 |
| Width of the packed product (mm) | 660 |
| Depth of the packed product (mm) | 670 |
| Minimum height for installation (mm) | 815 |
| Maximum height for installation (mm) | 875 |
| Minimum width for installation (mm) | 610 |
| Energy Efficiency Class | Tier 1 |
| Maximum width for installation (mm) | 618 |
| Depth for installation (mm) | 550 |
| Total annual energy consumption (kWh) | 240 |
| Net weight (kg) | 35.9 |
| Gross weight (kg) | 38.0 |
| Energy Star® qualified | Yes |
| Five-level wash | Yes |
| Reference programme | Eco |
| Number of place settings | 13 |
| Silence level (dBA) | 48 |
| Home Connect Connectivity | Wi-Fi |
| Home Connect | Remote Monitoring and Control |
| Number of different wash temperatures | 6 |
| Enter the minimum temperature for wash (°C) | 45 |
| Enter the maximum temperature for wash (°C) | 71 |
| Leak protection system | 24/7 Aqua Stop Plus |
| Water softener | Yes |
| Power consumption standby/network | Please check the user manual for how to switch off the WiFi module.: 2.0 |
| Maximum accepted water hardness | [50°DH] |
| Length inlet hose | 65'' |
| Maximum temperature for water intake (°C) | 60 |
| Drying system | Condensation Dry |
| Length outlet hose | 74 3/4'' |
| Start delay options | Continuous |
| Stop delay or a start delay option | Start |
| Start delay time max (h) | 24 |
| Required cutout size (HxWxD) | 32 1/8'' x 24'' x 24'' |
| Single basket washing | No possibility |
| Status indicator | End of program audible |
| Number of wash cycles | 5 |
| Digital countdown indicator | Yes |
| End of cycle sound | End of program audible |
| Salt light indicator | Yes |
| Rinse aid light indicator | Yes |
| List of programmes | Auto 127.4-131°F, Favorite, Intensive, Normal, Pre-rinse |
| Number of options | 5 |
| Cycle Options | Delicate, Extra Dry, HygienePlus, Machine Care, Remote Start |
| Automatic programmes | Yes |
| Safety device | triple water protection 24h |
| Interior light | No |
| Adjustable upper rack | Rackmatic 3-stage |
| Basket with handle | Bottom basket, Top basket |
| Software update | Yes |
| Optional accessories | SGZ1010UC, SMZ1008UC, SMZ5000, SMZ5002UC, SMZ5003 |
| UPC code | 825225970422 |
| Additional Image 1 | https://media3.bsh-group.com/Product_Shots/3000x3000/23225256_WorldsNo1_Dishwashers_Euromonitor.jpg |
| Additional Image 2 | https://media3.bsh-group.com/Product_Shots/3000x3000/17186169_SGV78B53UC_45_Degree_Angle_Door_Closed_def.jpg |
| Additional Image 3 | https://media3.bsh-group.com/Product_Shots/3000x3000/17186175_SGV78B53UC_Left_Side_View_def.jpg |
| Additional Image 4 | https://media3.bsh-group.com/Product_Shots/3000x3000/17186190_SGV78B53UC_Right_Side_View_def.jpg |
| Additional Image 5 | https://media3.bsh-group.com/Product_Shots/3000x3000/17186201_SGV78B53UC_Lifestyle_In_surrounding_area_door_closed_def.jpg |
| Additional Image 6 | https://media3.bsh-group.com/Product_Shots/3000x3000/17186202_SGV78B53UC_Lifestyle_Info_Light_If_available_def.jpg |
| Additional Image 7 | https://media3.bsh-group.com/Product_Shots/3000x3000/19659043_A01A04L55_INR_def.jpg |
| Total annual water consumption | 494 |
| Water Usage per Cycle | 3.2 |
| Net weight | 79.000 |
| Time auto-standby/network | 2.0 |
